Let’s be honest: the Squad server browser sucks. It takes forever to load, the refresh button is a placebo half the time, and specific servers just ghost you even when you know they’re up.

It’s frustrating because the data is there. The game isn’t intentionally hiding it; the UI is just choking on thousands of UDP packets while trying to render a 3D background. I got sick of waiting, so I decided to bypass the UI entirely and talk directly to the Master Server.

Here is how I reversed the Epic Online Services (EOS) API to build a zero-latency tracker that sees everything—even the “FireTeam” lobbies that usually make the menu freeze.

Pretending to be Steam

You can’t just ask for the server list anonymously. You need a valid session. I spent a while trying to see if I could replay an old token, but they expire pretty fast. To talk to the EOS backend, you effectively have to emulate a running Steam Client.

The game uses a “Steam Session Ticket” to prove you own the game. I used the steam-user library to run a headless Steam instance inside my Node app. It logs in, convinces Valve that I’m running Squad (AppID 393380), and grabs a cryptographically signed ticket.

async function _getEosAuthInternal(): Promise<IEOSAuthResponse> {
    const user = await getSteamUser();
    // We need a real ticket signed by Valve or EOS ignores us
    const ticket = await user.createAuthSessionTicket(393380);
    const cachedTicket = ticket.sessionTicket.toString("hex");

    const params = new URLSearchParams();
    params.append("grant_type", "external_auth");
    params.append("external_auth_type", "steam_session_ticket");
    params.append("external_auth_token", cachedTicket);
    // Hardcoded deployment ID for Squad found in Fiddler logs
    params.append("deployment_id", "5dee4062a90b42cd98fcad618b6636c2");

    // ... post request ...
}

The game then trades this Steam ticket for an EOS Access Token. This token is the golden key.

Filtering the Noise (The Query Logic)

The reason the in-game browser lags is mostly client-side processing. The API itself is actually incredibly snappy if you query it right.

The endpoint matchmaking/v1/.../filter uses a “Criteria” system. Instead of asking for everything and filtering it locally, I can tell the server exactly what I want.

For example, asking for servers that actually have players:

const body = {
    criteria: [
        // Don't waste bandwidth on empty servers
        { key: "attributes.PLAYERCOUNT_l", op: "GREATER_THAN", value: 0 },
        // Ignore local/co-op instances
        { key: "attributes.COOPSERVER_b", op: "EQUAL", value: false },
    ],
    maxResults: 50000,
};

This returns a JSON array of every populated server in milliseconds. No UI lag, no missing entries.

Hunting for FireTeams

Squad recently added “FireTeams”—pre-game lobbies where you group up. The browser technically supports them, but the implementation is so heavy that trying to load the list feels like pulling teeth. It lags, times out, or just fails to render half of them.

I started sniffing traffic while creating my own FireTeam to see what made them different in the API. They are technically standard “Servers,” just with specific flags set.

1. attributes.COOPSERVER_b is true.
2. attributes.LICENSEDSERVER_b is false (Unlicensed).
3. attributes.__EOS_BLISTENING_b is true.

I wrote a specific function to grab these immediately without the UI overhead.

export async function getRawFireteams(): Promise<ILobbies> {
  const auth = await getEosAuth();

  // These flags are the signature of a FireTeam lobby
  const body = {
    criteria: [
      { key: "attributes.COOPSERVER_b", op: "EQUAL", value: true },
      { key: "attributes.LICENSEDSERVER_b", op: "EQUAL", value: false },
      { key: "attributes.__EOS_BLISTENING_b", op: "EQUAL", value: true },
    ],
    maxResults: 200,
  };

  // ... execute request ...
}

Where are the names? (Resolving Players)

This was the trickiest part. The matchmaking API tells you how many players are in a server (PLAYERCOUNT_l), but it doesn’t tell you who.

I was digging through the server metadata and found a field called ADVERTISEDSESSIONID_s. It looked like a pointer to another system.

Turns out, there is a separate endpoint: lobby/v1/.../lobbies/filter. If you feed it a list of these Session IDs, it spits back the full roster.

export async function getPlayersInServers(serverIDs: string[]) {
  // Batch the IDs because EOS hates large payloads
  const batchRequests = serverIDBatches.map((batch) => {
    const body = {
      criteria: [
        {
          key: "attributes.ADVERTISEDSESSIONID_s",
          op: "ANY_OF",
          value: batch.map((id) => "Session:" + id),
        },
      ],
      maxResults: 35000,
    };
    // ... post request ...
  });

  // ... process responses ...
}

This gives us EOS Product User IDs. They are unique, but they aren’t Steam IDs. You can’t join their game or view their profile yet.

To finish the job, I had to use a third endpoint: user/v9/product-users/search. You send it a list of EOS IDs, and it returns the linked accounts.

By chaining these three calls (Server List -> Session Lookup -> User Resolve), I built a tracker that updates in real-time. It sees every server, identifies every player, and finds every FireTeam lobby, all without rendering a single frame of the game.
